Key Features:
Powerful MPPT solar charge controller with overload protection: compatible with solar panel(s), automatically activates when there is no battery-to-battery charging.
Fully-automatic, high-frequency, multi-stage charging: ensures the battery is charged safely and quickly. Pulsed charging keeps temperatures low and evens electrolyte consistency to ensure a long battery life.
Easy battery type selection: with the push of a button, the unit can be switched between Lead Acid, AGM/Gel, Calcium, or Lithium-ion battery types. The unit remembers the battery type even without power, so there is no need to reprogram the unit if the battery supply is turned off.
Safe unattended charging: the unit features inbuilt safety functions (protection against overload, overheating, overvoltage, over-discharge, short circuit, and reverse discharge of the battery), which allow the charger to be left permanently connected to the batteries for unattended automatic charging.
Continued charging during battery/load use: the charger will continue to operate at full power whilst energy is drawn from the battery during use. The unit will maintain the charge if the battery is already at full capacity. Any 12V loads may also be left permanently connected and running whilst the DC-to-DC charger is in operation, and will be protected against overvoltage and voltage fluctuations.
Ignition on/off control: by connection to the ignition control, this charger can be set to begin battery-to-battery charging immediately when vehicle ignition is turned on and stop charging when the vehicle is turned off.
Voltage sensing control: if the ignition is not wired then this charger can use smart voltage sensing to choose when DC-DC charging will start and which battery will be charged based on the battery voltage of the starter and main batteries.
Deep discharge recovery: with a soft-start charging program and a minimum output battery voltage of only 2.0V, this charger is capable of recovering batteries from extremely high depth of discharge.
Additional features:
This charger also features LED indicators to show target battery charging stage, power source and selected battery type.
Compatibility:
This DC-to-DC battery charger is suitable for use with any 12V lead acid, AGM, Gel, Calcium or Lithium batteries. It is not compatible with 24V batteries or a combination of 12V and 24V batteries.
